Telergon Switch disconnector, size 1, 3-pole, 250A
Telergon Switch disconnector, size 1, 3-pole, 250A

Telergon Switch disconnector, size 1, 3-pole, 250A Part number S5-02503PR0

This is a size 1, three-pole switch disconnector rated at 250 A, used to isolate three-phase circuits within control panels and switchgear enclosures. Its compact dimensions of 217 mm by 167 mm by 90 mm suit installation in space-constrained panel layouts. The unit carries certification to EN 60947-3 along with...
Vendor: Telergon
Rubicon Industrial Technology is the exclusive South African distributor for Telergon.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This is a size 1, three-pole switch disconnector rated at 250 A, used to isolate three-phase circuits within control panels and switchgear enclosures. Its compact dimensions of 217 mm by 167 mm by 90 mm suit installation in space-constrained panel layouts. The unit carries certification to EN 60947-3 along with Bureau Veritas, CCC, CE, EAC, IEL and IEC/IECEE marks, supporting compliance across a range of industrial applications.

Key specifications

  • Connection: 3P
Specifications
Specifications
x
Compliance/CertificationsBureau Veritas / CCC / CE / EAC / IEL / IEC/ IECEE / EN 60947-3
Part Depth (mm)90 mm
Part Width (mm)217 mm
Part Height (mm)167 mm
Weight (g)1700 g
Connection Type3P
Current Rating / Rated Current250 A
Operating Period20000 cycles
Documents
Documents
x
Download Datasheet
