Telergon Bypass switch disconnector, size 0, 3P + N, 125A Part number S5B01253NS0

Bypass changeover switches on-load, are available from 125 to 2000A in 3P – 3P+N & 4P versions under request on order. Uninterrupted duties in extreme tropic and polar conditions, as well as the polluted environment of any industrial process. Protection against accidental over voltages in equipment’s connected between phase and...
Vendor: Telergon
Rubicon Industrial Technology is the exclusive South African distributor for Telergon.
Availability: In stock
Product type: Control Panel
Please hurry! Only 2 left in stock
Description
Description
x

Bypass changeover switches on-load, are available from 125 to 2000A in 3P – 3P+N & 4P versions under request on order. Uninterrupted duties in extreme tropic and polar conditions, as well as the polluted environment of any industrial process. Protection against accidental over voltages in equipment’s connected between phase and neutral (our standard 3P+N) whit advanced switched neutral pole (early make – late break).

Specifications
Specifications
x
Rated thermal current Ith (A)125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 1800, 2000
Rated insulation voltage Ui (V)1000
Rated impulse withstand voltage Uimp (kV)8, 12
AC Rated operational current Ie (A) at Ue 400V125, 160, 200, 250, 315, 400, 500, 630, 800, 1000, 1250, 1600, 1800, 2000
Rated breaking capacity (A)375, 480, 600, 750, 945, 1200, 1500, 1890, 2400, 3000
Rated making capacity (A)375, 480, 600, 750, 945, 1200, 1500, 1890, 2400, 3000
Icm Short-circuit making capacity (kA peak)13, 20, 60
Icw Short-time withstand current (kA rms)7, 12, 16, 25
Number of mechanical operations8000, 5000, 3000
Maximum weight (Kg)2.4/2.8, 7.2/7.7, 16.5/17.5, 26.5/28.6, 65.2/72.1
Dimensions (mm)Various values for A, B, Ø based on sizes 0-4
Documents
Documents
x
Download Datasheet
