Staubli MGS1VS-R13-S Pin housing without cable gland

Product Overview

The 18.0106 is a shielded metal pin housing (MGS1VS-R13-S) from Stäubli's MGS1 series, providing EMC protection for multi-coupling connector applications requiring electromagnetic shielding and earth line connection for voltages exceeding 60 V DC or 30 V AC.

Key Features:

• EMC Shielding - Electromagnetic protection when used with EMC cable glands
• Metal Shielded Construction - Robust housing with mandatory PE earthing for voltages >60 V DC or >30 V AC
• Flexible Cable Routing - Two cable outlets with five directional configuration options
• Contact Carrier Shielding - Shield connection achieved through contact carrier for continuous EMC protection
• Spacer-Free Design - Configured for 13 mm plate spacing without additional spacers

Technical Specifications:

• Article Number: 18.0106
• Type: MGS1VS-R13-S
• Housing Size: G1
• Cable Gland Thread: R13
• Cable Outlets: 2 (5 directions)
• Plate Spacing: 13 mm
• Configuration: Shielded pin housing

Compatible Accessories:

• ME1 series contact insert sets
• E1 series contact carriers
• EMC cable glands (recommended: Pflitsch "Iris UNI Dicht")
• Blind plug 18.5652

Compliance & Certifications:

• Requires protective earth (PE) connection for voltages >60 V DC or >30 V AC

Applications:

Designed for industrial automation docking systems, robotic tool changers, automated multi-coupling applications, electrically sensitive measurement equipment, control system connections in high-interference environments, and manufacturing assembly lines requiring shielded connections with flexible cable routing and EMC protection.
