Product Overview

SIMATIC RF300; Reader RF340R (GEN2); RS422 interface (3964R); IP67, -25 to +70 °C, 75x 75x 41 mm with integrated antenna. HF reader for contact-free identification in closed production cycles in industrial production where very short cycle times are required. Article Number: 6GT2801-2BA10.

Key Specifications

RF Technology:

• Operating frequency: 13.56 MHz (HF)
• Transmission range: Up to 140 mm
• Radio transmission rate: 106 kbps
• Point-to-point transfer: 115.2 kbps
• Integrated antenna design

Interface & Communication:

• RS422 interface with 3964R protocol
• Baud rates: 19200, 57600, 115200 baud
• Maximum cable length: 1000 m (between reader and communication module)
• Compatible with SIMATIC S7 systems
• TIA Portal integration support

Environmental Specifications:

• Degree of protection: IP67
• Operating temperature: -25 to +70 °C
• Power supply: 24 VDC, 0.06 A
• Robust construction for industrial conditions
• High-quality materials for harsh environments

Physical Design:

• Dimensions: 75 × 75 × 41 mm
• Compact, welded housing
• Integrated antenna eliminates external connections
• Can be flush-mounted in metal
• M12 connector system

Physical Specifications

• Net weight: 0.3 kg
• Compact design: 75 × 75 × 41 mm
• Integrated antenna configuration
• Industrial-grade construction
• Robust housing for harsh environments

Product Identifiers

• EAN: 4047622417959
• UPC: 804766348686
• Country of origin: Germany

Compliance Information

• RoHS compliant since: 01.03.2003
• WEEE (2012/19/EU) Take-Back Obligation: Yes

REACH Regulation Information

Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): Lead, Lead monoxide (lead oxide), and Silicic acid, lead salt. Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.

Functionality

RFID Capabilities:

• Contact-free identification for high-speed production cycles
• Autonomous transponder data reading
• Automatic recognition of various transponder types (RF300, ISO 15693, MIFARE classic)
• Additional transponder protocol support for MOBY E transponders
• No special command control required

System Integration:

• Fully compatible with existing RF300 product family
• Integrated into SIMATIC Step 7 engineering systems
• TIA Portal commissioning support
• Direct connection to host systems
• Setup help for optimal antenna positioning

Performance Features:

• High-speed data transmission for short cycle times
• Robust against radio frequency interference
• High degree of data security
• Reliable operation in metallic environments
• LED operating status display

Applications

• Production and material handling control in industrial manufacturing
• Track-guided conveyor technology in mechanical engineering
• Assembly and auxiliary assembly lines in automotive industry
• Electrical appliance industry production lines
• Paint lines in automotive manufacturing
• Suspended monorail systems
• Baggage handling systems for airports
• Workpiece holder systems in closely packed assembly lines
