Siemens Simatic DP ET200 Pro fail-safe electronic module
View on Siemens 📄 Datasheet
Siemens

Siemens Simatic DP ET200 Pro fail-safe electronic module Part number 6ES7148-4FC00-0AB0

EAN / Barcode 4025515073055
Product Type Control Panel
Product Class Fieldbus, decentr. periphery - digital I/O module
ETIM Class Fieldbus, decentr. periphery - digital I/O module
In Stock
View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available
✓ RoHS Declaration

Product Description

Product Overview

SIMATIC DP ET200 PRO Fail-safe electronic module designed for critical safety applications. This advanced module features 4/8 F-DI/4 F-DO 24V DC/2A with PROFIsafe communication protocol, housed in a compact 90mm overall width design. The module meets the highest safety standards up to Category 4 (EN 954-1), SIL3 (IEC61508), and PLE (ISO13849), making it ideal for demanding industrial automation applications requiring fail-safe operation.

Key Features

  • Fail-safe digital input/output module with PROFIsafe communication
  • 4/8 fail-safe digital inputs and 4 fail-safe digital outputs
  • 24V DC operation with 2A current rating
  • Compact 90mm overall width design
  • Safety certification up to Category 4 (EN 954-1)
  • SIL3 (IEC61508) and PLE (ISO13849) compliant
  • Integrated safety functions for critical applications
  • ET200 PRO system compatibility

Technical Specifications

  • Article Number: 6ES7148-4FC00-0AB0
  • Voltage: 24V DC
  • Current Rating: 2A
  • Overall Width: 90mm
  • Net Weight: 0.316 kg
  • Packaging Dimensions: 11.60 x 13.70 x 7.00 cm
  • Quantity Unit: 1 Piece
  • EAN: 4025515073055
  • UPC: 662643188127
  • Country of Origin: Germany

Safety Certifications

  • Category 4 (EN 954-1) - Highest safety category for machinery control systems
  • SIL3 (IEC61508) - Safety Integrity Level 3 for functional safety
  • PLE (ISO13849) - Performance Level E for safety-related parts of control systems

Compliance & Certifications

  • Export Control: AL: N / ECCN: 9N9999
  • RoHS Compliance: Since 31.12.2008
  • WEEE (2012/19/EU): Take-back obligation applicable
  • Product Class: A - Standard product which is a stock item, returnable within guidelines

Applications

  • Safety-critical industrial automation systems
  • Emergency stop circuits
  • Safety door monitoring
  • Light curtain integration
  • Machine safety applications
  • Process safety systems
  • Hazardous area monitoring

Download existing graphical data for this product:

Technical Specifications

Depth65 mm
Digital inputs configurableYes
Digital outputs configurableYes
Fieldbus connection over separate bus coupler possibleYes
Front built-in possibleYes
Height130 mm
Input current at signal 13.7 mA
Number of digital inputs8
Number of digital outputs4
Output current2 A
Permitted voltage at input30 V
Permitted voltage at output0 V
Rail mounting possibleYes
Short-circuit protection, outputs availableYes
SIL according to IEC 615083
Suitable for safety functionsYes
Supply voltage DC20.4 V
Supporting protocol for PROFIsafeYes
System accessoryYes
Time delay at signal change17 ms
Type of digital outputTransistor
Type of output voltageDC
Type of voltage (input voltage)DC
Voltage type (supply voltage)DC
Wall mounting/direct mountingYes
Width90 mm
Part Width11 mm
Part Height13 mm
Part Depth7 mm
Weight316 g
Country of OriginGermany
View complete specifications on Siemens
