Siemens Simatic DP Electronic module for ET 200 Pro, 24VDC

Product Overview

SIMATIC DP electronic module for ET 200 PRO system featuring 16 digital inputs (DI) with 24V DC operation. This high-density digital expansion module includes integrated module diagnostics and comes with a bus module included. The connection module IO (6ES7194-4CB50-0AA0) must be ordered separately to complete the installation. Designed for comprehensive sensor monitoring and signal acquisition in IP65/67 distributed I/O systems, making it ideal for space-constrained applications requiring maximum input density.

Key Features

• 16 digital inputs (DI) for maximum sensor connectivity
• 24V DC operation with standard industrial voltage compatibility
• Integrated module diagnostics for comprehensive system monitoring
• Bus module included for seamless system integration
• Hot-swappable capability for maintenance without system shutdown
• Robust IP65/67 protection rating for harsh environments
• LED status indicators for individual channel monitoring
• Compact design maximizing input density per module

Technical Specifications

• Article Number: 6ES7141-4BH00-0AA0
• Input Type: 16 Digital Inputs (DI)
• Voltage: 24V DC
• Net Weight: 0.173 kg
• Packaging Dimensions: 7.30 x 14.00 x 6.50 cm
• Quantity Unit: 1 Piece
• EAN: 4025515078357
• UPC: 040892549638
• Country of Origin: Germany

System Requirements

• Connection Module: IO Connection Module 6ES7194-4CB50-0AA0 (must be ordered separately)
• System Compatibility: ET 200 PRO distributed I/O system
• Communication: PROFIBUS DP protocol
• Protection Rating: IP65/67 for outdoor and harsh environment applications

Compliance & Certifications

• Export Control: AL: N / ECCN: 9N9999
• RoHS Compliance: Since 20.10.2008
• WEEE (2012/19/EU): Take-back obligation applicable
• Product Class: A - Standard product which is a stock item, returnable within guidelines

Applications

• Multi-sensor monitoring systems
• Manufacturing process control with high input requirements
• Machine tool automation with extensive sensor networks
• Conveyor belt monitoring systems
• Building automation with multiple sensor inputs
• Process control systems requiring high input density
• Safety monitoring systems with multiple sensors
• Quality control systems with extensive sensor arrays

Advanced Features

• Hot Swapping: Allows module replacement without system shutdown
• Module Diagnostics: Real-time monitoring of module health and individual channel status
• High Input Density: 16 inputs in a single module for space efficiency
• Robust Construction: IP65/67 rating for harsh industrial environments
• Modular Design: Seamless integration with ET 200 PRO system architecture
• Individual Channel Monitoring: LED indicators for each input channel

Installation Notes

• Requires separate ordering of Connection Module IO (6ES7194-4CB50-0AA0)
• Module diagnostics provide comprehensive status monitoring for all 16 channels
• Hot-swappable design maintains system continuity during maintenance
• Compatible with standard ET 200 PRO mounting rails
• Suitable for direct machine installation without control cabinet
• Optimized for high-density sensor applications

Download existing graphical data for this product:

• Product Datasheet
• Product Support Page
