Siemens SD Low voltage motor, IE squirrel-cage, 4-pole, 160kW
📄 Datasheet
Siemens

Siemens SD Low voltage motor, IE squirrel-cage, 4-pole, 160kW Part number 1LE0023-3AB53-4JB4

Product Type Control Panel
Product Class Electric motor
ETIM Class Electric motor
Back Order
💬 Ask an Expert - Technical Support Available

Product Description

SD LOW-VOLTAGE MOTOR, IEC SQUIRREL-CAGE,SELF-VENTIL.,IP55 TEMP. CL. 155(F) ACC.TO 130(B) IE3,CAST-IRON HOUSING 4POLE * FS315L * 160KW (50HZ) Purchase of this product is exclusively governed by the Innomotics TCs located at https://www.innomotics.com/ terms-and-conditions

Technical Specifications

Breakdown torque ratio3
Full-load efficiency95.8 %
Nominal torque1027 Nm
Number of poles4
Power factor0.87
Rated current275 A
Rated rotational speed at rated frequency1488 1/min
Rated voltage400 V
Starting current ratio7.9
Starting torque ratio3
