Siemens Miniature circuit breaker, 3-pole, 400V, 15kA, 10A Part number 5SY7310-7CC

Product Overview

Siemens Miniature circuit breaker, 3-pole, 400 V, C-curve, 10 A (5SY7310-7CC) is a SENTRON series protective device designed for reliable overload and short-circuit protection in low-voltage electrical distribution systems. With a high breaking capacity, compact modular design and DIN rail mounting, this breaker offers robust protection for three-phase circuits in industrial, commercial and residential installations.

Key Features

• SENTRON miniature circuit breaker
• 3-pole protection for three-phase circuits
• Rated current: 10 A
• C-curve magnetic-thermal tripping characteristic
• High breaking capacity suitable for power distribution
• Compact modular housing for easy DIN rail installation
• Screw terminal connections for secure wiring
• Touch-protected and sealable design

Technical Specifications

• Article Number: 5SY7310-7CC
• Product Family: SENTRON 5SY7 miniature circuit breakers
• Device Type: Miniature circuit breaker (MCB)
• Number of Poles: 3
• Rated Current (In): 10 A
• Tripping Characteristic: C-curve
• Rated Operational Voltage: 400 V AC
• Rated Insulation Voltage (Ui): 440 V
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Breaking Capacity: 10 kA (EN 60898) / typical high capacity for SENTRON range
• Energy Limitation Class: 3
• Operational Frequency: 50 / 60 Hz
• Connection Type: Screw terminals (top and bottom)
• Connectable Conductor Cross-Section: 0.75 … 35 mm²
• Terminal Tightening Torque: 2.5 … 3.5 N·m
• Protection Class: IP20 with connected conductors
• Degree of Pollution: 3
• Overvoltage Category: III
• Mounting: DIN rail (any position)
• Modular Width Units: 3
• Dimensions (H × W × D): approx. 90 mm × 54 mm × 70 mm
• Weight (approx.): ~0.5 kg
• Operating Temperature: –25 °C to +55 °C
• Storage Temperature: –40 °C to +75 °C

Compliance & Certifications

• Manufactured to Siemens SENTRON industrial protection standards
• Designed to meet IEC 60898-1 and EN 60947-2 breaker requirements
• CE compliant
• RoHS compliant

Applications

The Siemens 5SY7310-7CC miniature circuit breaker is used to protect three-phase electrical circuits in industrial, commercial and residential distribution boards. It provides dependable overload and short-circuit protection for feeders, branch circuits and general power loads in distribution panels and control systems.
