Siemens Miniature circuit breaker, C-type, 1-pole, 230/400V, 1A

Product Overview

The Siemens 5SY4101-7 is a high-performance miniature circuit breaker designed for reliable electrical protection in ultra-low-current single-phase applications. This compact 1-pole circuit breaker features a 1 A current rating with 230/400 V operational voltage and enhanced 10 kA breaking capacity, making it ideal for protecting ultra-low-current single-phase electrical circuits, precision instrumentation, control equipment, and ultra-sensitive electronic devices from overloads and short circuits.

Key Features

• Enhanced 10 kA Breaking Capacity: Superior protection against fault currents with higher breaking capacity than standard breakers
• Single-Pole Configuration: Space-efficient solution for single-phase line protection in distribution panels
• C-Type Characteristic: Optimized for general applications with moderate inrush currents (5-10 times rated current)
• Ultra-Low Current Rating: 1 A rating perfect for precision instrumentation, control equipment, and ultra-sensitive devices
• Compact Design: Space-efficient construction suitable for standard DIN rail mounting (D=70 mm)
• German Engineering: Manufactured in Germany ensuring premium quality and reliability
• UL1077 Recognition: Certified as supplementary protector for enhanced circuit protection
• Tool-Free Installation: Double slide mechanism enables quick assembly and disassembly without tools

Technical Specifications

• Current Rating: 1 A
• Voltage Rating: 230/400 V AC
• Breaking Capacity: 10 kA
• Number of Poles: 1
• Trip Characteristic: C-type
• Net Weight: 0.155 kg
• Depth: 70 mm (D=70 mm)
• Width: 1 modular spacing (18 mm)
• Packaging Dimensions: 21.00 x 93.00 x 83.00 mm
• Country of Origin: Germany
• EAN: 4001869181301

Applications

This ultra-low-current 1-pole circuit breaker is particularly suitable for:

• Precision instrumentation circuits
• Ultra-sensitive electronic equipment protection
• Control panel auxiliary circuits
• Signal processing equipment
• Measurement and testing equipment
• Laboratory instrument protection
• Communication system circuits
• Sensor and monitoring circuits
• Low-power LED indicator lighting
• Electronic control modules
• Data acquisition systems
• Medical device circuits
• Security system components
• Building automation sensors
• Emergency shutdown circuits

Compliance & Certifications

• Standards Compliance: UL1077 recognized, IEC 60898-1/-2, IEC 60947-2, GB10963.1/.2, GB14048.2
• CE Marking: Complies with global standards for European markets
• RoHS Compliance: Compliant since January 1, 2006
• WEEE Directive: Subject to take-back obligations under directive 2012/19/EU
• REACH Regulation: Contains lead in concentrations higher than 0.1% w/w - safe when used as intended
• Export Control: AL: N / ECCN: N
• Product Class: B - Return restricted, contact Siemens partner for returns

Advanced Features

• Ultra-Precision Protection: Optimized for the most sensitive low-current applications
• Visual Status Indication: Window design with clear position indicators
• Touch Protection: Anti-finger contact terminal design for enhanced safety
• Dual-Chamber Terminals: Flexible conductor and busbar combinations
• Enhanced Safety: Insulated, dust-proof and anti-touch design
• Ergonomic Handle: Non-slip pattern handle for comfortable operation
• Modular Compatibility: Compatible with wide range of supplementary components
• Energy Limitation: Class 3 current limiting for enhanced protection
• Wide Conductor Range: Accommodates 0.75-35mm² conductor cross-sections

Product Classification

• eClass: 27-14-19-01 (versions 6-14)
• ETIM: EC000042 (versions 7-9)
• UNSPSC: 39-12-16-03
• IDEA: 4897
• Product Group: 5505
