Product Overview

Enclosure for command devices, 22 mm, round, enclosure material metal, enclosure top part gray, 4 control points, without equipment, recess for labels, floor mounting, 1xM25 each on top and bottom

Article Number: 3SU1854-0AA00-0AB1

Key Features:

• Size: 22 mm diameter, round configuration
• Material: Robust metal construction for enhanced durability
• Color: Professional gray top part
• Configuration: 4 control points design for complex multi-function applications
• Label Ready: Integrated recesses for custom labeling of all four control points
• Empty Design: Supplied without internal equipment for complete custom configuration
• Mounting: Floor mounting design with integrated cable management
• Cable Entry: 1x M25 cable gland on top and 1x M25 on bottom for larger cable requirements
• Series: SIRIUS ACT compatible

Technical Specifications:

• Diameter: 22 mm
• Shape: Round
• Material: Metal construction
• Top Part Color: Gray
• Control Points: 4
• Cable Entry: M25 threaded entries (top and bottom)
• Mounting Type: Floor mounting
• Net Weight: 0.812 kg
• Packaging Dimensions: 100.00 x 210.00 x 80.00 mm
• Quantity Unit: 1 Piece
• EAN: 4011209970274
• UPC: 804766075490
• Country of Origin: China

Product Benefits:

• Four Control Points: Maximum flexibility with four independent control positions for comprehensive command device configurations
• Metal Construction: Superior durability, EMI shielding, and protection compared to plastic versions
• Custom Configuration: Empty design allows for flexible installation of chosen internal components for each of the four control points
• Professional Appearance: Gray metal finish provides clean, industrial aesthetic suitable for demanding environments
• Quad Label Integration: Built-in recesses accommodate custom labeling for all four control points, ensuring clear component identification
• Enhanced Cable Management: M25 cable entries accommodate larger cable bundles and multiple circuits
• Floor Mounting: Optimized for ground-level installations with robust mounting capability
• Standard Size: 22mm diameter ensures compatibility with standard industrial panel cutouts
• Environmental Protection: Metal construction provides superior resistance to harsh industrial conditions
• System Foundation: Provides secure housing for complex multi-function SIRIUS ACT command device assemblies

Applications: Essential foundation component for complex multi-function SIRIUS ACT command device assemblies in industrial control stations, machinery operator panels, and automation systems requiring multiple independent controls. Perfect for applications requiring four-button configurations, start/stop/jog/emergency combinations, multi-mode selector arrangements, mixed control/indication functions, or comprehensive operator interface solutions where specific internal components are selected based on sophisticated application requirements. Ideal for manufacturing control stations, process control interfaces, and complex machinery operation panels.

Installation Notes: This enclosure requires separate procurement of internal components such as contact blocks, LED modules, actuators, and other command device elements for each of the four control points to create complete functional assemblies.

Configuration Options:

• Quad Pushbuttons: Four independent pushbutton controls
• Complex Control Combinations: Start/stop/jog/emergency configurations
• Multi-Mode Operations: Various selector switch and pushbutton arrangements
• Control/Indication Mix: Flexible mixing of control and indicator functions
• Custom Combinations: Complete flexibility in combining different control element types

Cable Management:

• M25 Entries: Larger cable glands accommodate multiple circuits and heavier cable bundles
• Dual Entry Points: Top and bottom access for complex wiring requirements
• Floor Mounting Compatible: Designed for ground-level cable routing and accessibility

Compatibility: Designed for use with SIRIUS ACT series internal components including contact modules, LED modules, pushbutton actuators, selector switch elements, and indicator lights for complete quad command device assembly.

Environmental Benefits:

• Metal Construction: Superior resistance to chemicals, UV exposure, temperature extremes, and mechanical stress
• EMI Shielding: Metal enclosure provides electromagnetic interference protection
• Corrosion Resistance: Industrial-grade metal materials designed for long-term durability
• Vibration Resistance: Robust construction withstands high-vibration industrial environments

Compliance & Certifications:

• RoHS Compliant: Since 01.10.2014
• Export Control: AL: N / ECCN: N
• Product Class: A - Standard stock item

REACH Regulation Notice: This product contains substances from the candidate list in concentrations higher than 0.1% w/w:

• Lead

Based on current information, these substances do not pose risk when used as intended. Please refer to product documentation for complete details.

Download existing graphical data for this product:
