Siemens Illuminable selector switch, metal, 3 position, black, 22mm Part number 3SU1052-2GL10-0AA0

Product Overview

The Siemens 3SU1052-2GL10-0AA0 is an illuminable selector switch (22 mm round cut-out) featuring a metal collar and a high-gloss metal front ring in black. It offers three switch positions (I-O-II) with latching operation and can be locked in positions O and I via two padlocks or a snap hook.

Key Features

• Illuminable selector switch for panel mounting (22 mm diameter)
• Metal collar and high-gloss metal front ring in black finish
• Selector handle, long version, with three switching positions: I, O and II
• Latching operation with actuating angle of ±45° (positions at ~10:30 h / 12 h / 13:30 h)
• Lockable in positions O + I with two padlocks or hook (shackle diameter 5 mm)
• Compatible with holder accessories and modular contact blocks

Technical Specifications

• Product Series: Siemens SIRIUS ACT (Selector Switches)
• Article Number: 3SU1052-2GL10-0AA0
• Mounting Size: 22.3 mm cut-out diameter (+0.4 mm tolerance)
• Installation Width × Height: ~48 mm × 48 mm
• Installation Depth: ~25.4 mm
• Number of Command Points: 1
• Actuating Element Design: Selector switch, long handle
• Number of Switching Positions: 3 (I-O-II)
• Actuating Angle: 2 × 45° (±45°)
• Locking Option: Lockable in O + I, with 2 padlocks or snap hook (shackle dia. 5 mm)
• Protection Class (Front): IP66 / IP67 / IP69 / IP69K
• Protection Class (Terminals): IP20
• Ambient Operating Temperature: –25 °C to +70 °C
• Storage Temperature: –40 °C to +80 °C
• Weight (Approx.): 0.061 kg (≈ 61 g)

Compliance & Certifications

• Complies with IEC/EN standards for selector switches and control-panel devices
• Designed for industrial automation environments and high-ingress protection applications

Applications

The 3SU1052-2GL10-0AA0 selector switch is ideal for machine control panels, automation enclosures and industrial installations where a robust, lockable selector function with three positions and integrated illumination is required. The high front protection class and metal finish make it suitable for demanding environments.
