Siemens Door-coupling rotary operated with door interlock

Product Overview

SKU 3VM9117-0FK21 - Door mounted rotary operator standard IEC IP65 with door interlock accessory for: 3VM10/11. This Siemens SENTRON accessory provides remote operation and enhanced safety features for 3VM series molded case circuit breakers through secure door-mounted control.

Key Features & Specifications

• Compatibility: Designed specifically for 3VM10 and 3VM11 series circuit breakers
• Mounting Type: Door-mounted rotary operator for external panel installation
• Protection Rating: IP65 sealed enclosure for dust and water protection
• Door Interlock: Integrated door interlock functionality for enhanced safety
• Standard Design: IEC standard compliant rotary operation mechanism
• Handle Type: Standard rotary handle for reliable manual operation

Performance Characteristics

• Remote Operation: Enables external control of circuit breaker without opening the panel
• Safety Integration: Door interlock prevents operation when panel door is open
• Environmental Protection: IP65 rating protects against dust ingress and water jets
• Reliable Mechanism: Robust rotary operator design for frequent operation
• Standard Compliance: Meets IEC standards for industrial applications
• Professional Installation: Designed for permanent panel door mounting

Physical Specifications

• Net Weight: 0.550 kg
• Packaging Dimension: 85.00 x 85.00 x 450.00 mm
• Packaging Quantity: 1 Piece

Safety Features

• Door Interlock System: Prevents circuit breaker operation when enclosure door is open
• IP65 Protection: Sealed design protects internal mechanisms from environmental hazards
• Mechanical Coupling: Secure mechanical connection to circuit breaker operating mechanism
• Safety Standards: Compliant with international electrical safety requirements

Applications

• Industrial Control Panels: Remote operation of circuit breakers in control enclosures
• Motor Control Centers: Enhanced safety and accessibility for MCC applications
• Distribution Panels: External control of main and feeder circuit breakers
• Process Control: Safe operation in industrial process control environments
• Hazardous Locations: IP65 protection suitable for challenging industrial environments
• Maintenance Operations: Simplified maintenance access and operation

System Benefits

Part of the SENTRON 3VM molded case circuit breaker system, offering:

• Enhanced safety through door interlock functionality
• Improved accessibility for circuit breaker operation
• Professional installation appearance with door-mounted design
• Environmental protection for reliable long-term operation
• Compliance with international safety and performance standards

Technical Advantages

• Door-Coupling Design: Secure mechanical coupling between door operator and circuit breaker
• IP65 Environmental Rating: Superior protection against dust and water ingress
• Interlock Safety: Door interlock prevents unsafe operation conditions
• Standard IEC Compliance: Meets international electrical standards
• Robust Construction: Designed for frequent operation in industrial environments
• Easy Installation: Straightforward mounting on panel doors

Installation Requirements

• Compatible exclusively with 3VM10 and 3VM11 series circuit breakers
• Requires proper mechanical coupling to circuit breaker operating mechanism
• Door interlock system must be properly connected for safety functionality
• IP65 rating maintained through proper installation procedures

Standards Compliance

• IEC standards compliant for rotary operator mechanisms
• IP65 environmental protection rating
• International electrical safety requirements
• RoHS conformity since 2014.10.01

Additional Information

• Country of Origin: Germany
• EAN: 4042949006039
• Article Number: 3VM9117-0FK21
• RoHS Conformity: Since: 2014.10.01
