Schneider Selector switch head, metal, black, 3-position, Ø 22
Schneider Selector switch head, metal, black, 3-position, Ø 22

Schneider Selector switch head, metal, black, 3-position, Ø 22

This selector switch actuator includes a 3-position mechanism and a key-operated feature for secure and controlled operation in industrial panels.
Vendor: Schneider Electric
SKU: ZB4BD7
Availability: In stock
Product type: Control Panel
Please hurry! Only 2 left in stock
Ask an expert
Description
Description
x
This selector switch actuator includes a 3-position mechanism and a key-operated feature for secure and controlled operation in industrial panels.
Specifications
Specifications
x
IP RatingIP66 / IP67 / IP69 / IP69K
Compliance/CertificationsBV / CSA / CSA C22.2 No 14 / DNV / GL / IEC 60947-1 / IEC 60947-5-1 / IEC 60947-5-4 / IEC 60947-5-5 / JIS C8201-1 / JIS C8201-5-1 / LROS (Lloyds register of shipping) / UL 508 / UL listed
Temperature: Operating-40 °C to 70 °C
Part Depth (mm)44mm
Part Width (mm)29mm
Part Height (mm)29mm
Weight (g)40g
Packaging size / unit1 / 5 / 100 pc(s)
Material: ProductChromium plated metal
Operating Period1000000 cycles (mechanical)
Warranty18 Months
ColourBlack
Documents
Documents
x
Download Datasheet
