Description
xSpecifications
x| Range of Product | Telemecanique Limit switches XC Standard |
| Series Name | Standard format |
| Product or Component Type | Limit switch body |
| Device Short Name | ZCKJ |
| Body Type | Fixed |
| Product Compatibility | XCKJ |
| Body Material | Metal |
| Contacts Type and Composition | 1 NC + 1 NO |
| Contact Operation | Snap action |
| Contacts Material | Silver plated contacts |
Complementary Information
| Electrical Connection | Male connector M12, 5 pins |
| Positive Opening | With |
| Resistance Across Terminals | 0.25 mOhm conforming to IEC 60255-7 category 3 |
| Terminals Description ISO n°1 | (23-24)NO, (21-22)NC, (11-12)NC, (13-14)NO |
Environmental Information
| IP Degree of Protection | IP66 |
| IK Degree of Protection | IK07 |
| Environmental Characteristic | High temperature |
