Schneider EasyPact CVS400F, Circuit breaker, 415 VAC, 400A Part number LV540505

Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Product Type Control Panel
Back Order
View Full Product Details on Schneider Electric 💬 Ask an Expert - Technical Support Available

Product Description

The Easypact CVS400 to 630 range of circuit breakers with Electronic trip unit technology is designed to guarantee the protection of all low-voltage electrical applications (cable or equipment) between 400 A and 630 A. This range consists of all products of Easypact CVS 400-630A family: 400-630F, 400-630H and 400 630N range. The environmental impacts of this referenced product are representative of the impacts of the other products of the range which are developed with a similar technology. The main function of the Easypact CVS product range is to protect the wires and equipments in the circuit when over current is over -- 80~400A (Overload Protection) or 800A(2In)/4000A(10In) (to realize short circuit current protection) in accordance with the Standard: IEC60947.2 for period of 20 years.

Technical Specifications

IP Rating / DetailedIP40
Compliance/CertificationsEN 60947-2,IEC 60947-2
Temperature: Operating-25…70 °C
Part Depth (mm)110mm
Part Width (mm)140mm
Part Height (mm)255mm
Connection TypeScrew connection
Max Frequency50/60 Hz
Type of VoltageAC
Mounting TypeFixed
Operating Period(Mech)15000 cycles
Operating Period(Elec)6000 cycles 415 V In conforming to IEC 60947-2
