Murr M12 female 0°, A-code with cable, 4-pole, black, 5m

Product Overview

The Murrelektronik M12 female straight connector is a pre-assembled cordset with integrated LED status indication for industrial sensor and actuator applications. This A-coded connector features a 5-meter PVC cable with 3x0.34mm² conductors and LED indicators, providing reliable connectivity with visual feedback in industrial automation environments where cost-effective solutions are required.

Key Features

• M12 female 0° straight connector with A-coding and LED status indication
• 5-meter PVC cable for standard industrial applications
• 3x0.34mm² conductors for signal transmission
• LED indicators for visual monitoring
• UL/CSA certification
• Gold-plated contacts for optimum conductivity
• Open-ended wire termination for flexible connections

Technical Specifications

• Article Number: 7000-12281-6130500
• Connector Type: M12 female 0° straight, A-coded
• Cable Length: 5 meters
• Conductor Specification: 3x0.34mm² PVC cable
• Voltage Rating: Up to 250V AC
• Current Rating: 4A maximum
• Operating Temperature: -25°C to +80°C
• LED Function: LED for status indication
• Cable Type: PVC (Polyvinyl Chloride), black
• Contact Material: Gold-plated for optimum conductivity
• Protection Rating: IP67 when mated

Applications

• Industrial sensor and actuator connections with visual status feedback
• Machine control signal transmission with LED monitoring
• Factory automation sensor networks requiring status indication
• Process control applications with diagnostic requirements
• Standard industrial environments with moderate temperature requirements

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Quality Standards: German engineering and manufacturing
• Protection Standards: Industrial-grade environmental protection with IP67 rating

Benefits

• Pre-assembled construction eliminates field termination errors
• LED indicators provide immediate visual status feedback
• PVC cable offers cost-effective solution for standard applications
• Gold-plated contacts ensure long-term reliable connectivity
• Straight design provides direct connection path
• Black cable jacket for professional appearance
• Resistance to common industrial environments

Download existing graphical data for this product:

• Data Sheet
