Lapp Skintop DIX-M Multiple sealing insert, M25, 2 x 6mm
Lapp Skintop DIX-M Multiple sealing insert, M25, 2 x 6mm

Lapp Skintop DIX-M Multiple sealing insert, M25, 2 x 6mm Part number 53325260

This multiple sealing insert allows for the routing of two cables through a single cable gland, offering IP68-rated protection when all openings are filled. Made of materials like NBR, FKM, and silicone, it provides chemical and oil resistance, supporting industrial applications in environments with high temperatures or demanding chemical exposure.
Vendor: Lapp Kabel
Availability: In stock
Product type: Cable & Cable Management
Please hurry! Only 40 left in stock
Description
Description
x
This multiple sealing insert allows for the routing of two cables through a single cable gland, offering IP68-rated protection when all openings are filled. Made of materials like NBR, FKM, and silicone, it provides chemical and oil resistance, supporting industrial applications in environments with high temperatures or demanding chemical exposure.
Specifications
Specifications
x
IP RatingIP 54 IP 68 (at maximum use of all boreholes)
Country of OriginGermany
Temperature: OperatingNBR: -40°C to 100°C / FKM: -20°C to 200°C / Silicone: -50°C to 200°C
MaterialFKM / NBR / Silicone
Article Designation Size20260 / M25
Pieces50 pc(s)
ColourBlack / Green / Blue
Documents
Documents
x
Download Datasheet
