Lapp H07V-K Power/control cable, orange, 6mm²
Lapp H07V-K Power/control cable, orange, 6mm²

Lapp H07V-K Power/control cable, orange, 6mm²

This cable is suitable for wiring devices and control cabinets. It has flame-retardant insulation and fine-wire copper conductors, providing reliable performance in industrial settings. It is designed for fixed installations in tubes and ducts and rated for 450/750V.
Vendor: Lapp Kabel
SKU: 4520094
Availability: Out Of Stock
Product type: Cable & Cable Management
Please hurry! Only 0 left in stock
Ask an expert
Description
Description
x
This cable is suitable for wiring devices and control cabinets. It has flame-retardant insulation and fine-wire copper conductors, providing reliable performance in industrial settings. It is designed for fixed installations in tubes and ducts and rated for 450/750V.
Specifications
Specifications
x
Compliance / Certifications cable type certification acc. EN 50525-2-31 / No cable type certified core insulation colours according to EN 50525-1/VDE 0285-525-1: all double colours (except of green-yellow and yellow-green), green (single colour), transparent, yellow (single colour)
Country of OriginGermany
FlammabilityFlame-retardent acc. to IEC 60332.1.2
Material: Inner Conductor / CoreFine-wire strand made of bare copper wires
Material: Insulation / Inner sheathPVC
Bending RadiusOD ≤ 8 mm: 4 x OD*/2 x OD**; 8 < OD ≤ 12 mm: 5 x OD*/3 x OD**; OD > 12 mm: 6 x OD*/4 x OD**
Drum Length / Coil Length100 m / ring
Weight 71000g
Test Voltage2500 V
ColourOrange (Core Colour)
Documents
Documents
x
Download Datasheet
