Lapp H07V-K Power/control cable, dark blue, 4mm²
Lapp H07V-K Power/control cable, dark blue, 4mm²

Lapp H07V-K Power/control cable, dark blue, 4mm²

This power and control cable features flame-retardant insulation and fine-wire copper conductors. It is designed for installations in control cabinets, tubes, and ducts, providing safe and reliable electrical performance in industrial environments. It is rated for 450/750V.
Vendor: Lapp Kabel
SKU: 4520143
Availability: In stock
Product type: Cable & Cable Management
Please hurry! Only 300 left in stock
Ask an expert
Description
Description
x
This power and control cable features flame-retardant insulation and fine-wire copper conductors. It is designed for installations in control cabinets, tubes, and ducts, providing safe and reliable electrical performance in industrial environments. It is rated for 450/750V.
Specifications
Specifications
x
Compliance / Certifications cable type certification acc. EN 50525-2-31 / No cable type certified core insulation colours according to EN 50525-1/VDE 0285-525-1: all double colours (except of green-yellow and yellow-green), green (single colour), transparent, yellow (single colour)
Country of OriginGermany
FlammabilityFlame-retardent acc. to IEC 60332.1.2
Material: Inner Conductor / CoreFine-wire strand made of bare copper wires
Material: Insulation / Inner sheathPVC
Bending RadiusOD ≤ 8 mm: 4 x OD*/2 x OD**; 8 < OD ≤ 12 mm: 5 x OD*/3 x OD**; OD > 12 mm: 6 x OD*/4 x OD**
Drum Length / Coil Length100 m / ring
Weight 45000g
Test Voltage2500 V
ColourDark blue (Core Colour)
Documents
Documents
x
Download Datasheet
