IDE Wander plug, 3P+E, 380/415V, 63A, IP67 Part number 03652N

This wander plug is a three-phase-plus-earth connector rated for 380/415V and 63A, with an IP67 enclosure rating for protection against dust and temporary immersion. It is used to provide detachable power connections in industrial installations where equipment or cabling needs to be connected and disconnected at the point of use....
Vendor: IDE
Rubicon Industrial Technology is the exclusive South African distributor for IDE.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This wander plug is a three-phase-plus-earth connector rated for 380/415V and 63A, with an IP67 enclosure rating for protection against dust and temporary immersion. It is used to provide detachable power connections in industrial installations where equipment or cabling needs to be connected and disconnected at the point of use. The IP67 rating suits applications where the connector may be exposed to washdown, wet conditions, or outdoor use.

Specifications
Specifications
x
Product TypeLow voltage wander plug
Current63A
Poles3P+E
Voltage380…415V
Frequency (Hz)50/60Hz
Time code6h
Weight0.678 kg
DimensionsNot specified
MaterialsHalogen-free plastic materials, polyamide 6, copper-zinc alloy
Degree of ProtectionIP66-IP67
Impact ResistanceIK08
Glow Wire Resistance960 ºC
Ball Pressure Test125 ºC
Ambient Temperature Range-25 ºC / +40 ºC
Directive2014/35/EU
StandardsIEC 60309-1-2
RoHS - REACHCompliant
Customs Tariff Number85.36.69.90
ETIM 8.0EC000140
Documents
Documents
x
Download Datasheet
