Description
xThis Weidmuller HDC HE 16 MS is a male insert for heavy-duty connectors, rated 500 V and 16 A across 16 poles, with screw connection terminals sized for conductors from AWG 20 to AWG 12. It is built in size 6 for use with a glass-fibre reinforced enclosure measuring 120 x 122 x 91mm, suitable for industrial connector housings operating between -40°C and 125°C. Typical applications include panel-to-panel or machine interconnections where multi-pole power and signal connections must be made and disconnected reliably in automation and control systems.
Key specifications
- Rated current: 16 A
- Material: Copper alloy
- Colour: beige
Specifications
x
| Version | HDC insert, Male, 500 V, 16 A, Number of poles: 16, Screw connection, Size: 6 |
| Order No. | 1207500000 |
| Type | HDC HE 16 MS |
| GTIN (EAN) | 4008190154790 |
| Qty. | 1 pc(s). |
Dimensions and Weights
| Depth | 84.5 mm (3.327 inch) |
| Height | 35.7 mm (1.406 inch) |
| Width | 34 mm (1.339 inch) |
| Net Weight | 81.84 g |
Temperatures
| Limit Temperature | -40 °C to 125 °C |
Environmental Product Compliance
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption | 6c |
| REACH SVHC | Lead 7439-92-1, Potassium perfluorobutane sulfonate 29420-49-3 |
| SCIP | e98b2b24-ba23-41bf-8d19-0dda3647412f |
Chemical Resistance
| Substance | Chemical Resistance |
| Acetone | Resistant |
| Ammonia, watery | Conditionally resistant |
| Petrol | Resistant |
| Benzene | Resistant |
| Diesel oil | Conditionally resistant |
| Acetic acid, concentrated | Resistant |
| Potassium hydroxide | Conditionally resistant |
| Methanol | Conditionally resistant |
| Motor oil | Conditionally resistant |
| Lye, diluted | Resistant |
| Hydrochlorofluorocarbons | Conditionally resistant |
| Outdoor use | Conditionally resistant |
General Data
| BG | 6 |
| Colour | beige |
| Conductor Cross-section | 2.5 mm² |
| Free from Halogens | true |
| Insulating Material | PC glass-fibre reinforced (UL-listed and railway-certified) |
| Insulating Material Group | IIIa |
| Insulation Strength | 1010 Ω |
| Low Smoke acc. DIN EN 45545-2 | Yes |
| Material | Copper alloy |
| Max. Torque for Main Contact | 0.55 Nm |
| Min. Torque for Main Contact | 0.5 Nm |
| Number of Poles | 16 |
| Plugging Cycles, Silver | ≥ 500 |
| Pollution Severity | 3 |
| Rated Current (DIN EN 61984) | 16 A |
Connection Data PE
| Blade Size, Slotted (PE Connection) | SD 0.8 x 4.0 |
| Connection Type PE | Screw connection |
| Fixing Screw | M 4 |
| Rated Cross-section | 4 mm² |
| Stripping Length PE Connection | 10 mm |
| Tightening Torque, Max. PE Connection | 1.5 Nm |
| Tightening Torque, Min. PE Connection | 1.2 Nm |
| Wire Cross Section, AWG (PE), Max. | AWG 12 |
| Wire Cross Section, AWG (PE), Min. | AWG 20 |
Approvals
| Approvals |
 |
| ROHS | Conform |
| Certificate No. (cURus) | E92202 |
