Siemens Sirius Soft starter, screw terminals, 200 - 480V, 171A

Product Overview

SIRIUS soft starter 200-480 V 171 A, 110-250 V AC Screw terminals. This high-performance soft starter is designed for demanding industrial applications requiring precise motor control with high current capacity. It provides smooth motor acceleration and deceleration while offering advanced control features for optimal motor protection and energy efficiency.

Technical Specifications

Article Number: 3RW5536-6HA14

Electrical Characteristics:

• Current rating: 171 A
• Power rating: 90 kW at 400 V
• Supply voltage: 200-480 V AC
• Control voltage: 110-250 V AC
• Terminal type: Screw terminals
• Phases: Three phase
• IP rating: IP00

Motor Control Features:

• Soft start capability for smooth motor acceleration
• High current capacity for demanding applications
• Overcurrent protection
• Thermal overload protection
• Reduced starting currents
• Mechanical stress reduction
• Advanced motor protection features

Physical Properties:

• Net weight: 10.000 kg
• Packaging dimensions: 402.00 x 304.00 x 328.00 mm
• Packaging quantity: 1 piece
• Country of origin: Czech Republic

Product Identifiers:

• EAN: 4047621040998
• UPC: Not available

Compliance & Environmental:

• RoHS Compliance: Since 15.02.2018
• WEEE Take-Back Obligation: Yes
• REACH Regulation: Contains lead, lead monoxide, 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol, 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one, 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol, dibutylbis(pentane-2,4-dionato-O,O')tin, lead titanium trioxide, and N,N-dimethylacetamide in concentrations higher than 0.1% weight by weight. Based on current information, these substances do not pose risk when used as intended.

Classifications:

• eClass: 27-37-09-07
• ETIM: EC000640
• UNSPSC: 39-12-15-21

Download existing graphical data for this product:

• Technical Datasheet (PDF)
• 3D CAD Models
• CAD Drawings (DWG/DXF)
• Product Details - Industry Mall
