Siemens Simatic IPC277E Nanopanel PC, 7" touch TFT Part number 6AV7882-0AA10-0AA0

Product Overview

The Siemens SIMATIC IPC277E (SKU: 6AV7882-0AA10-0AA0) is a rugged industrial Nanopanel PC with a 7-inch touchscreen display designed for machine-side HMI applications. It features a capacitive 7″ TFT touch display, dual Gigabit Ethernet ports, DisplayPort interface, USB 3.0 and USB 2.0 ports, a serial COM1 interface, and a CFast slot for storage. Powered by a 24 V DC supply, it is built for continuous operation in demanding industrial environments where reliability and long-term availability are essential.

Key Features

• 7″ capacitive touch TFT display for intuitive operator control
• Two 10/100/1000 Mbps Ethernet RJ-45 ports for high-speed connectivity
• DisplayPort graphics output for external monitor connection
• One USB 3.0 and two USB 2.0 ports for peripheral integration
• Serial COM1 port for communication with legacy equipment
• CFast slot for solid-state storage and easy data access
• 24 V DC power input (19.2–28.8 V) for industrial use
• Compact fanless design suitable for continuous operation

Technical Specifications

• Product Family: SIMATIC IPC277E Nanopanel PC
• Article Number: 6AV7882-0AA10-0AA0
• Display Size: 7″ TFT capacitive touchscreen
• Processor: Intel Celeron N2807 dual-core (embedded)
• Memory: 2 GB DDR3 RAM (expandable)
• Storage Interface: CFast slot
• Ethernet Interfaces: 2 × RJ-45 (10/100/1000 Mbps)
• USB Ports: 1 × USB 3.0 and 2 × USB 2.0
• Serial Port: 1 × COM1 (RS-232/422/485)
• Display Output: DisplayPort
• Power Supply: 24 V DC (19.2–28.8 V)
• Mounting: Panel mounting / machine integration
• Protection: Front IP65 (installed), rear IP20
• Cooling: Fanless, maintenance-free operation
• Country of Origin: Germany

Compliance & Certifications

• CE compliant and built to Siemens industrial PC standards
• Designed for long-term operation in harsh industrial environments
• Complies with EN 61000 industrial EMC standards
• RoHS compliant and environmentally safe

Applications

Ideal for machine-side operation and visualization in compact automation systems, control cabinets, and panel-mounted machinery. It is commonly used in packaging machines, material-handling systems, manufacturing equipment, and other industrial environments requiring a reliable and high-performance embedded HMI solution.
