Siemens Simatic HMI TP1200 Comfort panel, touch, 12" TFT

SKU / Article No. 6AV2124-0MC01-0AX0

Product Type Control Panel

Product Class Graphic panel

R 56,340.00

In Stock

View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available

Product Description

Product Overview

Mid-range SIMATIC HMI Comfort Panel designed for touch operation applications. This industrial-grade human-machine interface features a 12" widescreen TFT display with enhanced memory capacity and comprehensive connectivity options, delivering reliable performance for automation monitoring and control applications requiring a balance of screen size and functionality.

Key Features

Display Technology: 12" widescreen TFT display with 16 million colors
Operation Method: Touch operation for intuitive user interaction
Connectivity: PROFINET interface and MPI/PROFIBUS DP interface
Memory: 12 MB configuration memory for application storage
Operating System: Windows CE 6.0 for stable industrial operation
Configuration: Compatible with WinCC Comfort V11 software
Panel Type: SIMATIC HMI TP1200 Comfort Panel

Technical Specifications

Display Size: 12" widescreen format
Color Depth: 16 million colors
Memory Capacity: 12 MB configuration memory
Communication Interfaces: PROFINET, MPI/PROFIBUS DP
Net Weight: 3.460 kg
Packaging Dimensions: 36.20 x 50.90 x 12.60 cm
Quantity Unit: 1 Piece
EAN: 4025515079002
UPC: 040892686050
Country of Origin: Germany

Compliance

RoHS Compliance: Compliant since January 31, 2011
Export Control: AL: N / ECCN: 9N9999
WEEE Take-Back Obligation: Yes

Environmental & Safety Information

This product meets industrial environmental standards and contains several substances listed under REACH Article 33 regulations in concentrations higher than 0.1% by weight, including Lead, Silicic acid lead salt, Bisphenol A (BPA), and Lead monoxide. When used as intended, including proper disposal, these substances do not pose risk to users.

Configuration & Software

Designed for seamless integration with Siemens automation systems, this HMI panel is configurable using WinCC Comfort V11 software, providing comprehensive tools for creating intuitive operator interfaces and system monitoring solutions. The 12" display size offers an optimal balance between screen real estate and installation space requirements.

Download existing graphical data for this product:

For technical documentation and detailed specifications, please refer to the official Siemens support resources:

Technical Specifications

IP Rating	IP (at the front) IP65 IP (rear) IP20
Country of Origin	Germany
Temperature: Operating	0°C - +50°C
Weight (g)	2 800g
Packaging size / unit	pc(s)
Type of Voltage	DC
Supply Voltage	24 V (DC Rated Value) / 19.2 V (DC Lower Limit) / 28.8 V (DC Upper limit)
Current Consumption	0.85A
