Siemens IOT2050 Advanced intelligent gateway, 2x Gbit Ethernet RJ45 Part number 6ES7647-0BA00-1YA2

Product Overview

The Siemens 6ES7647-0BA00-1YA2 is the Siemens SIMATIC IOT2050 Advanced gateway featuring 2x Gbit Ethernet RJ45, DisplayPort, 2x USB 2.0, and an SD card slot with integrated 16 GB eMMC storage. It is designed as a compact and rugged industrial IoT edge device for data acquisition, protocol conversion, connectivity, and processing between field devices and higher-level automation, IT, or cloud systems.

Key Features

• Industrial IoT gateway from the SIMATIC IOT2050 Advanced series
• 2 × Gigabit Ethernet ports for high-speed communication
• DisplayPort interface for monitor or HMI output
• 2 × USB 2.0 ports for peripheral or storage devices
• Built-in 16 GB eMMC storage plus SD card slot for expansion
• Powered by a high-performance ARM-based processor suitable for edge computing
• 2 GB DDR4 RAM for improved processing and gateway performance
• Compatible with 12/24 V DC industrial power supplies
• Includes Arduino and mPCIe expansion slots for modular hardware upgrades
• Rugged enclosure and design suitable for continuous industrial operation
• DIN-rail or cabinet mounting for easy integration into control panels

Technical Specifications

• Article Number: 6ES7647-0BA00-1YA2
• Product Type: SIMATIC IOT2050 Advanced Industrial Gateway
• Processor: ARM TI AM6548 processor platform
• Memory: 2 GB DDR4 RAM
• Internal Storage: 16 GB eMMC
• Expansion Storage: SD card slot
• Ethernet Ports: 2 × Gbit Ethernet RJ45
• USB: 2 × USB 2.0
• Video Output: DisplayPort
• Expansion Interfaces: 1 × Arduino slot, 1 × mPCIe slot
• Operating Voltage: 12/24 V DC
• Stored-Energy Time: Approximately 5 ms during supply interruption
• Temperature Range: 0 °C to +50 °C
• Protection Class: IP20 when installed
• Mounting: DIN-rail or control-cabinet installation
• Weight: Approximately 0.435 kg

Compliance & Certifications

• Designed for industrial automation environments
• Suitable for continuous operation under standard industrial conditions
• Part of the SIMATIC IOT product family

Applications

The SIMATIC IOT2050 Advanced gateway is used for data collection, protocol conversion, edge processing, IoT connectivity, and smart automation tasks. It supports integration of field devices with SCADA systems, PLC networks, cloud platforms, and remote monitoring systems. Typical applications include industrial IoT solutions, machine data logging, predictive maintenance, factory modernization, and connecting legacy equipment to modern digital platforms.
