Siemens Gas burner control, t1=31.5s, TSA=3s, AC230V

Product Overview

The Siemens LGK16.333A27 – Gas burner control, t₁ = 31.5 s, TSA = 3 s, AC 230 V – is a control unit designed for continuously operating multi-stage or modulating burners of medium to high capacity. It features self-checking flame supervision, air-pressure monitoring, and is suitable for gas, oil or dual-fuel forced-draft burners.

Key Features

• Gas burner control unit for forced-draft burners (gas, oil or dual-fuel)
• Fixed start-up time t₁ = 31.5 seconds
• Safety time TSA = 3 seconds
• Rated for AC 230 V supply (50/60 Hz)
• Self-checking flame signal amplifier for safe operation
• Air-pressure monitoring ensures correct combustion-air supply
• Designed for continuously operating multistage or modulating burners of medium to high capacity

Technical Specifications

• Article Number: LGK16.333A27
• Control Type: Gas burner control unit (LGK16 series)
• Supply Voltage: 230 V AC, 50/60 Hz
• Start-up Time (t₁): 31.5 s
• Safety Time (TSA): 3 s
• Application: Forced-draft burners, gas/oil/dual-fuel, medium to high capacity
• Functionality: Self-checking flame supervision, air-pressure supervision, modulating/multistage capability

Compliance & Certifications

• Manufactured under Siemens industrial burner-control quality standards
• Designed for use in combustion plants with safety requirements on flame supervision

Applications

Ideal for industrial combustion systems, boilers, process heaters and large heating plants requiring safe, controlled ignition, monitoring and shutdown of burners. Suitable for plant owners, OEMs and system integrators deploying multistage or modulating burners in industrial or utility-scale installations.
