Siemens Box terminal, 3 units for 3VA4/5 125

Product Overview

The Siemens 3VA9133-0JA11 is a professional box terminal designed for 3VA51 series molded case circuit breakers. This TS1.1 terminal system provides reliable single wire connections for conductors ranging from 14 AWG to 3/0, offering steel construction for durable electrical connections in industrial and commercial power distribution applications. The 3-unit set ensures comprehensive connection coverage.

Key Features

• Single Wire Configuration: Designed for individual conductor connections with reliable termination
• Wide Cable Range: Accommodates 14 AWG to 3/0 conductors for versatile application requirements
• Steel Construction: Durable steel terminals for long-lasting electrical connections
• 3-Unit Set: Complete terminal configuration with 3 single terminals included
• TS1.1 System: Professional-grade box terminal design for secure connections
• Compact Design: Efficient 170 x 120 x 15 mm packaging dimensions

Technical Specifications

• Product Type: Box terminal, single wire connection
• Cable Range: 14 AWG to 3/0 conductors
• Compatibility: 3VA51 series circuit breakers (125A)
• Configuration: 3 units (3 single terminals)
• Material: Steel construction with copper compatibility
• Article Number: 3VA9133-0JA11
• Net Weight: 0.088 kg
• Packaging Dimensions: 170.00 x 120.00 x 15.00 mm
• Country of Origin: China
• EAN: 4042949016649

Applications

• Industrial power distribution systems with 3VA51 circuit breakers
• Commercial electrical installations requiring single wire connections
• Manufacturing facilities with 125A capacity requirements
• Switchgear applications requiring steel terminal construction
• Power distribution panels with individual conductor terminations

Installation Features

• Single Wire Design: Individual terminals for flexible wiring configurations
• Steel Terminals: Robust construction for reliable electrical connections
• Copper Compatibility: Designed for copper conductor connections
• Professional Grade: Engineered for industrial and commercial applications
• Easy Installation: Straightforward mounting and connection process

Compliance & Certifications

• RoHS Compliance: Since January 1, 2016
• WEEE Directive: Subject to take-back obligations
• REACH Regulation: Monitored according to current requirements
• Export Control: AL: N / ECCN: N
