Siemens 2x Gbit Ethernet RJ45, Display port, 2x USB2.0, SD card slot Part number 6ES7647-0BA00-0YA2

Product Overview

The Siemens 6ES7647-0BA00-0YA2 is the Siemens 2x Gbit Ethernet RJ45, Display port, 2x USB2.0, SD card slot industrial IoT gateway, part of the SIMATIC IOT2050 Basic series. It is a compact, robust edge device designed for data acquisition, protocol conversion and industrial communication, enabling the integration of field devices, automation systems and higher-level IT or cloud platforms.

Product Overview

The Siemens 6ES7647-0BA00-0YA2 is the Siemens SIMATIC IOT2050 Basic industrial IoT gateway. It is a compact and robust edge device designed for data acquisition, processing and communication in industrial automation environments. With Ethernet connectivity, USB interfaces, expandable storage and a 24 V DC industrial power supply, it enables secure integration of field devices with higher-level systems, cloud services or analytics applications.

Key Features

• SIMATIC IOT2050 Basic series industrial IoT gateway
• Two Gigabit Ethernet ports for network communication
• Two USB 2.0 ports for peripheral or storage device connection
• DisplayPort interface for connection to a monitor when required
• microSD card slot for data storage expansion
• ARM-based processor platform suitable for edge processing and IoT applications
• 1 GB DDR4 memory for gateway, communication or light compute tasks
• 12/24 V DC industrial power input
• Compact housing designed for DIN-rail or cabinet installation
• Rugged, industrial-grade design suitable for continuous operation
• Supports software frameworks for IoT connectivity, data handling and automation integration

Technical Specifications

• Article Number: 6ES7647-0BA00-0YA2
• Product Type: SIMATIC IOT2050 Basic industrial IoT gateway
• Processor: ARM TI AM6528 GP
• Memory: 1 GB DDR4 RAM
• Networking: 2 × Gigabit Ethernet (RJ45)
• USB Ports: 2 × USB 2.0
• Display Output: DisplayPort interface
• Storage Expansion: microSD card slot
• Operating Voltage: 12/24 V DC
• Power Interruption Buffer: Approximately 5 ms stored-energy time
• Mounting: DIN-rail or cabinet installation
• Housing Protection: IP20 when installed
• Operating Temperature Range: 0 °C to +50 °C
• Weight: Approximately 0.427 kg
• Design: Compact, enclosed module suitable for industrial control panels

Compliance & Certifications

• Part of the SIMATIC IOT portfolio designed for industrial communication and automation connectivity
• Meets industrial standards for electronic equipment used in control cabinets
• Suitable for factory automation, infrastructure and process-related applications

Applications

The SIMATIC IOT2050 Basic gateway is used for data acquisition, protocol conversion, cloud connectivity, machine-to-machine communication and edge analytics. It is commonly found in smart factory environments, industrial IoT projects, machine retrofitting, energy monitoring, SCADA integration, predictive maintenance systems and distributed automation networks. Its robust design and industrial interfaces make it ideal for cabinet-mounted automation and IoT solutions.
