Description
xThis variable speed drive controls the speed of three-phase induction motors rated at 0.37kW, operating from a 380...500V supply. It provides an RS485 multidrop serial link for communication with control systems, and carries an IP20 rating on its upper part when the cover plate is not fitted. The drive is designed for panel mounting, with operating temperature limits varying according to whether the protective top cover is in place. It is suitable for automation applications requiring compliance with IEC 61800-5-1 and IEC 61800-3.
Key specifications
- IP rating: IP20 on upper part without cover plate
Specifications
x| IP Rating / Detailed | IP20 on upper part without cover plate |
| Compliance/Certifications | IEC 61800-5-1,IEC 61800-3 |
| Temperature: Operating | -10…50 °C without derating (with protective cover on top of the drive) -10…60 °C with derating factor (without protective cover on top of the drive) |
| Part Depth (mm) | 152mm |
| Part Width (mm) | 107mm |
| Part Height (mm) | 143mm |
| Communication | port protocol |
| Supply Voltage | 380...500 V - 15...10 % |
| Interface | RS485 multidrop serial link |
