Description
xThis contactor is designed for motor control and resistive loads. It features a 3-pole configuration with a 230 V AC coil and a rated operational current of 9 A for AC-3 applications. It supports a rated operational voltage of up to 690 V.
Specifications
x| IP Rating | IP2X |
| Compliance/Certifications | CB Scheme / CCC / CE / CSA / CSA C22.2 No 60947-4-1 / EAC / EN / GB / IEC 60335-1:Clause 30.2 / IEC 60335-2-40:Annex JJ / IEC 60947-4-1 / JIS C8201-4-1 / T 14048. |
| Part Depth (mm) | 57mm |
| Part Width (mm) | 45mm |
| Part Height (mm) | 58mm |
| Weight (g) | 180g |
| Connection Type | Screw clamp terminals 1 cable(s) 1.5 - 4 mm²solid / Screw clamp terminals 1 cable(s) 0.75 - 4 mm²flexible without cable end / Screw clamp terminals 1 cable(s) 0.34 - 2.5 mm²flexible with cable end / Screw clamp terminals 2 cable(s) 1.5 - 4 mm²solid / Screw clamp terminals 2 cable(s) 0.75 - 4 mm²flexible without cable end / Screw clamp terminals 2 cable(s) 0.34 - 1.5 mm²flexible with cable end |
| Rated Operating Voltage | 690 VAC |
| Mounting Type | Plate / Rail |
| Current Rating / Rated Current | 6A |
| Operating Period | 10 Mcycles (mechanical) / 1.3 Mcycles 6 A AC-3 at Ue <= 440 V / 1.3 Mcycles 6 A AC-3e at Ue <= 440 V / 0.05 Mcycles 36 A AC-4 at Ue <= 440 V (electrical) |
| Warranty | 18 Months |
