Description
xThis tap-off unit for Canalis KN systems supports 32 A and includes a plug-in mounting design for efficient low-power distribution in industrial electrical setups.
Specifications
x| IP Rating | IP55 |
| Compliance/Certifications | IEC 61439-1 / IEC 61439-6 |
| Part Depth (mm) | 95mm |
| Part Width (mm) | 135mm |
| Part Height (mm) | 165mm |
| Weight (g) | 600g |
| Packaging size / unit | 1 pc(s) / 44 pc(s) |
| Max Frequency | 50/60 Hz |
| Rated Operating Voltage | 230 - 500 V depending on protective device |
| Warranty | 18 Months |
| Colour | White |
| RAL Code | RAL 9001 |
