Description
xThis metal safety switch features a turret head, slow break contacts (1 NC + 2 NO), and a high IP67 rating, making it ideal for secure industrial operations.
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CSA / CSA C22.2 No 14 / EN 1088/ISO 14119 / IEC 60204-1 / IEC 60947-5-1 / ISO 12100 / UL / UL 508 |
| Temperature: Operating | France |
| Temperature: Operating | -25°C to 70°C |
| Part Depth (mm) | 44 mm |
| Part Width (mm) | 40 mm |
| Part Height (mm) | 114 mm |
| Weight (g) | 440 g |
| Packaging size / unit | 1 / 20 pc(s) |
| Material: Product | Metal / Zamak |
| Current Rating / Rated Current | 0.27 A at 250 V, DC-13, Q300 conforming to IEC 60947-5-1 / 0.55 A at 125 V, DC-13, Q300 conforming to IEC 60947-5-1 / 3 A at 240 V, AC-15, A300 conforming to IEC 60947-5-1 / 6 A at 120 V, AC-15, A300 conforming to IEC 60947-5-1 |
