Description
xThis light block is a plastic body and fixing collar assembly in orange, fitted with a 1NO contact block for use in pilot light or indicator applications on control panels. It operates from a 24 V AC/DC supply at 50/60 Hz and terminates via screw clamp terminals, with silver alloy (Ag/Ni) contacts rated across a range of AC and DC switching conditions. Its operating temperature range of -40 to 70°C and compact dimensions (30 x 42 x 32 mm) suit installation within panel-mounted control and signalling assemblies.
Key specifications
- Connection: Screw clamp terminals, = 1 x 0.22 mm² without cable end conforming to EN 60947-1
- Operating temperature: -40…70 °C
- Colour: Orange
Specifications
x| Compliance/Certifications | JIS C8201-5-1,EN/IEC 60947-5-1,EN/IEC 60947-1,EN/IEC 60947-5-4,UL 508,CSA C22.2 No 14,JIS C8201-1 |
| Temperature: Operating | -40…70 °C |
| Part Depth (mm) | 32mm |
| Part Width (mm) | 30mm |
| Part Height (mm) | 42mm |
| Material: Product | Silver alloy (Ag/Ni) |
| Screw Type | Cross compatible with Philips no 1 screwdriver,Cross compatible with pozidriv No 1 screwdriver,Slotted compatible with flat Ø 4 mm screwdriver,Slotted compatible with flat Ø 5.5 mm screwdriver |
| Connection Style | 1 NO |
| Connection Type | Screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1,Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1 |
| Supply Voltage | 24 V AC/DC at 50/60 Hz |
| Current Rating | 3 A at 240 V, AC-15, A600 conforming to EN/IEC 60947-5-1,6 A at 120 V, AC-15, A600 conforming to EN/IEC 60947-5-1,0.1 A at 600 V, DC-13, Q600 conforming to EN/IEC 60947-5-1,0.27 A at 250 V, DC-13, Q600 conforming to EN/IEC 60947-5-1,0.55 A at 125 V, DC-13, Q600 conforming to EN/IEC 60947-5-1,1.2 A at 600 V, AC-15, A600 conforming to EN/IEC 60947-5-1 |
| Current Consumption | 18 mA |
| Operating Period(Mech) | 5000000 cycles |
| Operating Period(Elec) | 1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C,1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C,1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C,1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C,1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C |
| Colour | Orange |
