Description
xThis light block is a body and fixing collar assembly for panel-mounted pilot light indication, rated for a 24 V AC/DC supply at 50/60 Hz with a current consumption of 18 mA. It is finished in blue and fitted with screw clamp terminals for cable connection, accepting a range of Philips, Pozidriv and slotted screwdriver types. Operating over a temperature range of -40 to 70°C, it is suited to control panel applications requiring status or signal indication in demanding environments.
Key specifications
- Connection: Screw clamp terminals, = 1 x 0.22 mm² without cable end
- Operating temperature: -40…70 °C
- Colour: Blue
Specifications
x| Compliance/Certifications | EN/IEC 60947-1,CSA C22.2 No 14,EN/IEC 60947-5-1,JIS C8201-5-1,UL 508,EN/IEC 60947-5-5,EN/IEC 60947-5-4,JIS C8201-1 |
| Temperature: Operating | -40…70 °C |
| Part Depth (mm) | 37mm |
| Part Width (mm) | 30mm |
| Part Height (mm) | 47mm |
| Screw Type | Cross compatible with Philips no 1 screwdriver,Cross compatible with pozidriv No 1 screwdriver,Slotted compatible with flat Ø 4 mm screwdriver,Slotted compatible with flat Ø 5.5 mm screwdriver |
| Connection Type | Screw clamp terminals, <= 2 x 1.5 mm² with cable end,Screw clamp terminals, >= 1 x 0.22 mm² without cable end |
| Supply Voltage | 24 V AC/DC at 50/60 Hz |
| Current Consumption | 18 mA |
| Colour | Blue |
