Schneider Inductive sensor, cylindrical, M18, 12 - 48VDC Part number XS618B1PBM12

This cylindrical inductive sensor detects the presence of metallic targets without physical contact, providing a switching output for control circuits. Its M18 threaded body suits mounting on machine frames, conveyors and panels where space for sensor housings is limited. Operating on a 12 to 48VDC supply, it is suitable for...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Field Sensing & Connectivity
Please hurry! Only 0 left in stock
Description
Description
x

This cylindrical inductive sensor detects the presence of metallic targets without physical contact, providing a switching output for control circuits. Its M18 threaded body suits mounting on machine frames, conveyors and panels where space for sensor housings is limited. Operating on a 12 to 48VDC supply, it is suitable for typical automation and process control applications requiring proximity detection of metal parts.

Specifications
Specifications
x
Product data sheetXS618B1PBM12
Thread typeM18 x 1
Detection faceFrontal
Front materialPPS
Enclosure materialNickel plated brass
Sensing range> 4...8 mm
Operating zone0…6.4 mm
Differential travel1...15% of Sr
Status LEDOutput state: 1 LED (yellow)
Supply voltage limits10…58 V DC
Switching frequency<= 1000 Hz
Maximum voltage drop<2 V (closed)
Current consumption<= 10 mA no-load
Maximum delay first up10 ms
Maximum delay response0.3 ms
Maximum delay recovery0.7 ms
MarkingCE
Threaded length52 mm
Length74 mm
Net weight0.04 kg
Jul 30, 20241
Product certificationsUL[RETURN]CSA[RETURN]E2
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-40…85 °C
Vibration resistance25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
Shock resistance50 gn for 11 ms conforming to IEC 60068-2-27
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height2.600 cm
Package 1 Width4.900 cm
Package 1 Length11.800 cm
Package 1 Weight60.000 g
Unit Type of Package 2S02
Number of Units in Package 244
Package 2 Height15.000 cm
Package 2 Width30.000 cm
Package 2 Length40.000 cm
Package 2 Weight3.203 kg
