Schneider Inductive proximity sensor, 24 - 240VAC/DC Part number XS1M12MA250

This inductive proximity sensor detects the presence of metallic targets without physical contact, operating across a 24-240VAC/DC supply range. It provides a switching output signal used for position sensing and object detection in automation and control circuits. Typical applications include control panels and machine builds where non-contact metal detection is...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x

This inductive proximity sensor detects the presence of metallic targets without physical contact, operating across a 24-240VAC/DC supply range. It provides a switching output signal used for position sensing and object detection in automation and control circuits. Typical applications include control panels and machine builds where non-contact metal detection is required.

Specifications
Specifications
x
Product data sheetXS1M12MA250
Thread typeM12 x 1
Detection faceFrontal
Front materialPPS
Enclosure materialNickel plated brass
Operating zone0…1.6 mm
Differential travel1...15% of Sr
Cable composition2 x 0.34 mm²
Wire insulation materialPVC
Status LEDOutput state: 1 LED (yellow)
Supply voltage limits20…264 V AC/DC
Maximum residual current1.5 mA open state
Switching frequency<= 4000 Hz DC <= 25 Hz AC
Maximum voltage drop<5.5 V (closed state)
Maximum delay first up70 ms
Maximum delay response0.2 ms
Maximum delay recovery0.2 ms
MarkingCE
Threaded length42 mm
Dec 18, 20241
Length57 mm
Net weight0.075 kg
Product certificationsCCC[RETURN]UL[RETURN]CSA
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-40…85 °C
Vibration resistance25 gn amplitude = +/- 2 mm (f = 10…55 Hz) conforming to IEC 60068-2-6
Shock resistance50 gn for 11 ms conforming to IEC 60068-2-7
SCIP Number3bc2f5da-1620-4d53-878c-410a857f3212
Circularity ProfileEnd of Life Information
Warranty18 months
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height4.2 cm
Package 1 Width9.6 cm
Package 1 Length13 cm
Package 1 Weight94 g
Unit Type of Package 2S02
Number of Units in Package 222
Package 2 Height15 cm
Package 2 Width30 cm
Package 2 Length40 cm
Package 2 Weight2.523 kg
