Description
xThis illuminated blue signaling unit is designed for modular tower lights, providing steady illumination with energy-efficient LED technology. It ensures high visibility and reliability in industrial environments.
Specifications
x| IP Rating | IP65 / IP66 |
| Compliance/Certifications | CCC / CSA C22-2 No 14 / EAC / EN / IEC 60947-5-1 / UL 508 |
| Temperature: Operating | -25 °C to 50 °C |
| Part Depth (mm) | 70mm |
| Part Width (mm) | 70mm |
| Part Height (mm) | 63mm |
| Weight (g) | 150g |
| Packaging size / unit | 1 / 36 / 288 pc(s) |
| Material: Product | \nPolycarbonate |
| Connection Type | Screw clamp terminals / <= 1 x 1.5 mm² with cable end |
| Supply Voltage | 24 VAC/DC |
| Current Consumption | < 47 mA AC/DC |
| Warranty | 18 Months |
