Schneider Illuminated unit for tower lights, blue, Ø 70 Part number XVBC2B6

This is an illuminated unit for a Ø70 tower light, providing a blue signal indication when fitted to a tower light assembly. It operates from a 24 V AC/DC supply with a current consumption below 47 mA, and connects via screw clamp terminals accepting cables up to 1.5 mm² with cable end. Fitted to the XVBZ0 fixing base, the assembly achieves IP65 protection, suitable for status indication on machinery and control panels operating between -25°C and 50°C.

Key specifications

• IP rating: IP65 on fixing base XVBZ0. conforming to IEC 60529
• Connection: Screw clamp terminals, <= 1 x 1.5 mm² with cable end
• Operating temperature: -25…50 °C
