This is an empty control station enclosure with eight cut-outs sized for 22mm control devices, allowing engineers to combine pushbuttons, selector switches, indicator lights and other components in a single housing. The die-cast construction provides a durable enclosure body, finished in blue. It is typically used where multiple control and signalling functions need to be grouped at a machine or panel, with the operator selecting and fitting the required 22mm devices into the pre-cut openings.
| Range of product | Harmony XAP |
| Product or component type | Die-cast empty control station |
| Device short name | XAPM |
| Product destination | For Ø 22 mm control and signalling units |
| Product front plate size | 80 x 220 mm |
| Usable depth | 74.5 mm |
| Number of cut-out | 8 cut-outs |
| Colour of base of enclosure | Blue |
| Colour of cover | Blue |
| Material | Zinc alloy |
| Cable entry | 1 hole without blanking plug for cable gland, clamping capacity: 18 mm |
| Device mounting | Flush |
| IP degree of protection | IP65 conforming to IEC 60529 |
| Number of vertical rows | 2 |
| Net weight | 1.37 kg |
| Protective treatment | TC |
| Ambient air temperature for | -40…70 °C |
| Overvoltage category | Class I conforming to IEC 60536 Class I conforming to NF C 20-030 |
| Dec 19, 2024 | 1 |
| Warranty | 18 months |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 13.1 cm |
| Package 1 Width | 8.3 cm |
| Package 1 Length | 23.5 cm |
| Package 1 Weight | 1.531 kg |
