Description
xThis EasyPact TVS contactor features 3 poles (3 NO) and is rated for 18 A at 440 V AC-3 and 32 A for AC-1. It supports motor control applications up to 9 kW at 415 V AC and operates with a 240 V AC coil.
Specifications
x| IP Rating | IP2X conforming to IEC 60529 |
| Country of Origin | Germany |
| Compliance/Certifications | CE / EAC / IEC 60947-1 / IEC 60947-4-1 / IEC 60947-5-1 |
| Temperature: Operating | -5°C to 55 °C |
| Part Depth (mm) | 80mm |
| Part Width (mm) | 45mm |
| Part Height (mm) | 74mm |
| Weight (g) | 300g |
| Packaging size / unit | 1 pc(s) |
| Tightening Torque | Power circuit: 1.2 Nm Control circuit: 1.2 Nm |
| Connection Style | 3 Poles / 3 NO |
| Connection Type | Power circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end Power circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: solid without cable end Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid without cable end Power circuit: screw clamp terminals 1 1.5…6 mm² - cable stiffness: solid without cable end Power circuit: screw clamp terminals 2 1.5…6 mm² - cable stiffness: solid without cable end |
| Rated Operating Voltage | 690 VAC |
| Mounting Type | Din rail / Plate |
| Current Rating / Rated Current | 32 A at <= 415 VAC /18 A at <= 440 VAC |
| Operating Period | 10000000 cycles (Mechanical) / 300000 cycles AC-1\n1200000 cycles AC-3 (Electrical) |
| Warranty | 18 Months |
