Approval | CE, UKCA, cULus Listed, EAC (Eurasian), TÜV |
Sensor Principle | Magnetic |
Coding Level to ISO 14119 | Low |
Classification to EN 60947-5-3 | PDDB |
Suitable for Series Connection | No |
Unit Type | Unit |
Supply Voltage (V) | 24 V |
Type of Supply Voltage U1 | DC |
Switching Voltage | 24 V |
Ambient Temperature | -25 to 70 °C |
Max. Ambient Temp. at Hmax | |
Max. Ambient Temp. at 2000 m | +70 °C |
Climatic Suitability Standard | IEC 60068-2-30 |
Humidity Rating | 93 % r. h. at 40 °C |
Perm. Operating Height ASL | 2000 m |
EMC to Standard | EN 60947-5-3 |
Vibration to Standard | EN 60947-5-2 |
Acc. Shock to Standard | 30g |
Pollution Degree Clear & Creep | 3 |
Protection Type, Housing |
Type 1 Actuator | PSEN ma1.3-08 |
Sensor Can Be Flush-Mounted | Yes, follow installation guide |
Connection Type | M12, 5-pin male |
Cable Lines | Li9Y11Y 8 x 0.14 mm2 |
Housing Material Upper Part | PBT |
Height Dimension | 11 mm |
Width Dimension | 12 mm |
Depth Dimension | 59.1 mm |
Net Weight | 30 g |
Gross Weight | 62 g |
RoHS Directive | 2011/65/EU, 2015/863/EU |
RoHS Conformity | Yes |
RoHS Exceptions | No |
REACh Compliance | Contains no SVHC substances |
WEEE Classification | 5 devices (feed size < 50cm) |
ECLASS Version | ECLASS-13 |
ECLASS Reference Feature | 27274401 |
ETIM Version | ETIM-9.0 |
ETIM Reference Group | EG000026 |
ETIM Reference Feature | EC002544 |
UNSPSC 25 | 39122205 |
GTIN | 4046548064780 |
Volume | 0 dm3 |
Harmonized System Code | 85365019 |
Type of Tariff Number | TARIC |
Use of Customs Tariff Number | Ausfuhr, Einfuhr |
Quantity per Packaging Unit | 1 |
