Murr MVP12V-ON9F-PNGH Distribution module, 24VDC

Product Overview

The Murrelektronik Master Breakout Box PNP is a central signal collection and distribution module designed for industrial camera connectivity systems. This essential component serves as the single common element in vision systems, collecting and distributing various signals across camera networks while providing simplified cabling, fast installation, LED diagnostics, and space reduction benefits.

Key Features

• Central signal collection and distribution for camera systems
• PNP (Positive-Negative-Positive) configuration for industrial applications
• LED diagnostic indicators for system monitoring
• Combines multiple functions in one compact module
• Trigger and encoder signal management capability
• Simplified cabling solution for vision systems

Technical Specifications

• Model: Master Breakout Box PNP
• Article Number: 277415
• Configuration: PNP (Positive-Negative-Positive)
• Application: Camera connectivity and signal distribution
• Signal Types: Trigger, encoder, and power signal management
• Integration: Central component for vision system architecture

Signal Management Features

• Signal Collection: Centralized collection of various system signals
• Signal Distribution: Efficient distribution across camera networks
• Trigger Signal Processing: Management of trigger signals for synchronized operation
• Encoder Signal Handling: Processing and distribution of encoder signals
• Power Signal Integration: Combines power and control signals onto single cables

System Integration Capabilities

• Central Hub Function: Single common component for all vision systems
• Multi-Signal Processing: Handles trigger, encoder, and power signals simultaneously
• Camera Network Support: Enables connection to multiple cameras and devices
• Daisy-Chain Compatibility: Supports power daisy-chain architectures
• Injection Box Interface: Sends signals to injection boxes for field distribution

Diagnostic and Monitoring

• LED Diagnostics: Visual status indication for system monitoring
• System Status: Real-time feedback on signal and power conditions
• Troubleshooting Support: Simplified diagnostics for maintenance
• Operational Visibility: Clear indication of system operational status
• Fault Detection: Early identification of system issues

Installation Benefits

• Simplified Cabling: Reduces complex wiring requirements
• Fast Installation: Streamlined setup and configuration process
• Space Reduction: Compact design saves control cabinet space
• Modular Design: Easy integration with other system components
• Plug & Play Operation: Simplified connection and setup

Vision System Architecture

• Central Distribution Point: Hub for all vision system signals
• Camera Integration: Direct interface to camera networks
• Field Distribution: Connects to injection boxes for field-level distribution
• Power Management: Coordinates power and signal distribution
• System Scalability: Supports expandable camera installations

Applications

• Industrial vision systems and machine vision applications
• Manufacturing automation with multiple camera setups
• Quality control and inspection systems
• Production line monitoring and control
• Barcode reading and identification systems
• Dimensional inspection and quality control applications

Connectivity Features

• Multi-Port Configuration: Multiple connection points for various signals
• Industrial Connectors: Robust connection system for harsh environments
• Signal Integrity: Maintains signal quality through distribution
• Power Distribution: Efficient power management for connected devices
• Field Compatibility: Designed for industrial field installation

Standards and Compliance

• Industrial Standards: Compliant with industrial automation standards
• PNP Configuration: Standard positive-negative-positive logic
• Quality Assurance: Murrelektronik industrial quality standards
• Reliability Standards: Professional-grade signal processing
• Vision System Standards: Optimized for industrial image processing

Benefits

• Centralizes signal management for vision systems
• Simplifies installation and reduces wiring complexity
• Provides comprehensive diagnostic capabilities
• Enables scalable camera network architectures
• Reduces control cabinet space requirements
• Improves system reliability and maintenance efficiency
