Murr M12, male 0° / female 0°, A-code, 4-pole, black, 10m

Product Overview

The Murrelektronik M12 connection cable is designed for industrial automation signal transmission applications requiring enhanced flexibility. This pre-assembled cable features M12 male straight connector to M12 female straight connector configuration with A-coding, providing reliable signal connections for sensors, actuators, and other industrial devices. The 10-meter PUR cable with drag chain capability and UL/CSA certification offers superior performance for demanding automation applications with dynamic movement requirements.

Key Features

• M12 male straight to M12 female straight connector configuration
• A-coded connectors for standardized signal applications
• 10-meter PUR cable with superior flexibility and drag chain capability
• 4x0.34mm² conductor specification for signal transmission
• UL/CSA certification for North American compliance
• Black cable jacket for professional appearance
• IP67 protection rating for harsh environments
• Extended length for maximum equipment separation and signal extension
• Pre-assembled construction for immediate installation
• Chemical and oil resistant plastic housings

Technical Specifications

• Article Number: 7000-40021-6141000
• Connector Type: M12 male straight to M12 female straight
• Coding: A-coded
• Cable Length: 10 meters
• Conductor Specification: 4x0.34mm² (#22 AWG)
• Cable Type: PUR (Polyurethane), black jacket
• Protection Rating: IP67
• Certification: UL/CSA approved
• Features: Drag chain capable
• Application Category: Signal transmission and connectivity
• Housing Material: Plastic with chemical and oil resistance

Applications

• Industrial sensor signal transmission over extended distances
• Dynamic automation applications requiring drag chain compatibility
• Robotic system signal connections with continuous movement
• Equipment interconnection requiring 10-meter separation
• Control panel to remote field device signal connectivity
• Machine automation signal distribution across large facilities
• Process control signal routing between distant equipment stations
• Custom automation projects requiring certified flexible long-distance cables

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Protection Standard: IP67 rating for dust and water resistance
• Drag Chain Standards: Certified for dynamic flex applications
• Quality Standards: German engineering and manufacturing
• Safety Standards: Compliant with industrial automation requirements
• Connection Standards: M12 A-coded for standardized compatibility
• Chemical Resistance: Tested for oils and chemicals (application-specific testing recommended)

Benefits

• Pre-assembled construction eliminates field termination requirements
• A-coded configuration ensures proper connection orientation
• PUR cable provides superior flexibility for dynamic applications
• UL/CSA certification ensures North American compliance
• IP67 rating protects against environmental contamination
• Drag chain capability enables use in moving automation applications
• 10-meter length provides maximum flexibility in equipment positioning
• Optimized conductor size for efficient signal transmission
• Professional black jacket appearance suitable for visible installations
• Chemical resistant housings ensure durability in industrial environments

Download existing graphical data for this product:

• Data Sheet
