IDE Interlock socket wall, blue, 2P+E, 16A, 200/250V - Rubicon Partner Portal
IDE Interlock socket wall, blue, 2P+E, 16A, 200/250V - Rubicon Partner Portal

IDE Interlock socket wall, blue, 2P+E, 16A, 200/250V Part number 02831

IP44-IP67 Interlocking sockets, IP67 WALL INTERLOCKING SOCKET 2P+E 220V 16A 6H. Manufactured with high-durability halogen-free plastics and are available in a range of from 10 to 125 Amperes and from 24 to 500 Volts, with IP44-IP54-IP67 protection. The material used is: Plastic parts: polyamide 6. Contacts: copper-zinc alloy. Halogen-free plastic...
Vendor: IDE
Rubicon Industrial Technology is the exclusive South African distributor for IDE.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
IP44-IP67 Interlocking sockets, IP67 WALL INTERLOCKING SOCKET 2P+E 220V 16A 6H. Manufactured with high-durability halogen-free plastics and are available in a range of from 10 to 125 Amperes and from 24 to 500 Volts, with IP44-IP54-IP67 protection. The material used is: Plastic parts: polyamide 6. Contacts: copper-zinc alloy. Halogen-free plastic materials. Supplied in an individual box per packaging multiple.
Specifications
Specifications
x
Product typeLow voltage wall interlocking socket
Current16A
Poles2P+E
Voltage200/250 V
Weight0.696 kg
MaterialsHalogen-free plastic materials, polyamide 6, copper-zinc alloy
Degree of protectionIP67
Resistance to impactIK08
Glow wire resistance960 ºC
Ball pressure test125 ºC
Ambient temperature range-25 ºC / +40 ºC
Directive2014/35/EU
StandardsIEC 60309-1-2
Documents
Documents
x
Download Datasheet
