Description
xThis illuminated pushbutton from Euchner features a yellow LED indicator with a transparent pressure hood and black housing, allowing individual labelling for clear identification on control panels. It operates with a snap-action switching element providing one normally open and one normally closed contact, connected via soldered terminals. The device is rated IP65 when installed and suited to ambient temperatures between -25°C and 55°C, making it appropriate for use in safety automation panels and machine control interfaces.
Key specifications
- Connection: Soldered connection
- Operating temperature: -25 - 55 °C
Specifications
x
| LED display | 14 mA 24 V |
Electrical connection values
| Contact resistance | max. 50 mΩ New value |
| Switching voltage | |
| AC/DC | max. 250 V |
| Switching current | max. 5000 mA |
| Switching characteristics | Key function |
Mechanical values and environment
| Connection type | Soldered connection |
| Number of switching elements | 2 1 NO contact, 1 NC contact |
| Switching principle | Snap-action switching element |
| Degree of protection | IP65 (When installed) |
| Ambient temperature | -25 - 55 °C |
Miscellaneous
| Color | |
| Pressure hood | transparent |
| Housing | black |
| LED | Yellow |
| Additional feature | can be individually labeled |
Downloads
Hand-Held Pendant Stations/Handwheels
Shipping Details
| Item designation | LEUCHTDRUCKTASTER MIT LED GELB |
| Gross weight | 0,01kg |
| Customs tariff number | 85389099990 |
