Elfin Push-button enclosure, 2 hole Ø 22, 92x92x70mm
Elfin Push-button enclosure, 2 hole Ø 22, 92x92x70mm

Elfin Push-button enclosure, 2 hole Ø 22, 92x92x70mm

This aluminum control station box by NewElfin measures 92x92x70 mm and provides a robust enclosure solution for push buttons with one Ø22 mm opening. It has a grey RAL7035 finish and offers IP66, IP69, and Type 4X protection ratings, ideal for various industrial applications.
Vendor: Elfin
SKU: 040C0909-7EP2
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
This aluminum control station box by NewElfin measures 92x92x70 mm and provides a robust enclosure solution for push buttons with one Ø22 mm opening. It has a grey RAL7035 finish and offers IP66, IP69, and Type 4X protection ratings, ideal for various industrial applications.
Specifications
Specifications
x
IP RatingIP66 - IP69 - TYPE 4, 4X (IEC-EN60529 - NEMA 250
Tariff No85381000
Country of OriginChina
Compliance/CertificationsCE / CSA / EAC / IEC-EN62208 / UL / UL508 / CSA C22.2 No.14-13
Temperature: Operating-40°C to100°C
Part Depth (mm)92mm
Part Width (mm)92mm
Part Length (mm)70mm
Tightening Torque2.5Nm
Material: ProductAluminium
Material: GasketCork rubber
Material: ScrewAISI 304 / Stainless steel
Screw TypeM4 - cross head Phillips 2
Warranty18 Months
ColourGrey
RAL CodeRAL 7035
Documents
Documents
x
Download Datasheet
