Description
xnan
Specifications
x| IP Rating | IP6x / IPx9K |
| Compliance/Certifications | Ecolab CE cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | PC / ABS |
| Material: Sensing Surface / Contacts | PMMA |
| Part Depth (mm) | 51mm |
| Part Width (mm) | 23mm |
| Part Height (mm) | 52.4mm |
| Connection Type | M12x1 / Male / 4-pin / A-coded |
| Tightening Torque | 1.5 Nm |
| Rated Operating Distance (mm) | 14 000mm (adjustable) |
| Switching Output | PNP normally closed (NC) PNP normally open (NO) |
| Switching Frequency (Hz) | 600 Hz |
| Rated Insulation Voltage | 75 VDC |
| Operating Voltage | 10 - 30 VDC |
| Rated Voltage | 24 V |
| Mounting Type | Screw M4 |
| Rated Operating Current | 100 mA |
