Description
xnan
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | cULus CE UKCA WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-plated |
| Material: Sensing Surface / Contacts | Glass |
| Part Length (mm) | 75mm |
| Part Diameter (mm) | 18mm |
| Connection Type | M12x1 / Male / 4-pin |
| Tightening Torque | 15 - 30 Nm |
| Rated Operating Distance (mm) | 20 000mm (adjustable) |
| Switching Output | PNP normally open/normally closed (NO/NC) |
| Switching Frequency (Hz) | 400 Hz |
| Rated Insulation Voltage | 250 VAC |
| Operating Voltage | 18 - 30 VDC |
| Rated Voltage | 24 V |
| Interface | IO-Link 1.1 |
| Mounting Type | Nut M18x1 |
| Rated Operating Current | 100 mA |
