IP Rating | IP65 |
Compliance/Certifications | CE WEEE / IEC 60947-5-2, IEC 60947-5-7 |
Material: Housing / Grip | Zinc die casting |
Material: Sensing Surface / Contacts | Glass |
Part Depth (mm) | 100.5mm |
Part Width (mm) | 30mm |
Part Height (mm) | 73.2mm |
Connection Type | M12x1 / Male / 4-pin |
Rated Operating Distance (mm) | 2000mm (adjustable) |
Switching Output | PNP/NPN NO/NC push-pull |
Operating Voltage | 18 - 30 VDC |
Rated Voltage | 24 V |
Mounting Type | Screw M5 |
Rated Operating Current | 100 mA |
