Description
xnan
Specifications
x| IP Rating | IP68 |
| Compliance/Certifications | CE UKCA cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-free coated |
| Material: Jacket / Cover Nut | PVC |
| Material: Sensing Surface / Contacts | PBT |
| Size | M12x1 |
| Cable Length (mm) | 5 000mm |
| Cable Diameter (mm) | 4.7mm |
| Conductor Cross-section | 0.34 mm² |
| Tightening Torque | 10Nm |
| Rated Operating Distance (mm) | 4mm |
| Switching Output | PNP normally open (NO) |
| Switching Frequency (Hz) | 2500 Hz |
| Rated Insulation Voltage | 250 VAC |
| Operating Voltage | 10 - 30 VDC |
| Rated Voltage | 24 V |
| Rated Operating Current | 200 mA |
